ChunkHandler Struct Reference

Handlers and description of chunk. More...

#include <saveload.h>

Inheritance diagram for ChunkHandler:

Public Member Functions
	ChunkHandler (ChunkId id, ChunkType type)
	Create this ChunkHandler.
virtual	~ChunkHandler ()=default
	Ensure the destructor of the sub classes are called as well.
virtual void	Save () const
	Save the chunk.
virtual void	Load () const =0
	Load the chunk.
virtual void	FixPointers () const
	Fix the pointers.
virtual void	LoadCheck (size_t len=0) const
	Load the chunk for game preview.
std::string	GetName () const
	Get the name of this chunk.

Data Fields
ChunkId	id
	Unique ID (4 letters).
ChunkType	type
	Type of the chunk.

Detailed Description

Handlers and description of chunk.

Definition at line 456 of file saveload.h.

Constructor & Destructor Documentation

ChunkHandler()

ChunkHandler::ChunkHandler ( ChunkId id, ChunkType type )

inline

Create this ChunkHandler.

Parameters

id	The unique identifier/name of this chunk.
type	The type of chunk

Definition at line 465 of file saveload.h.

References id, and type.

Referenced by NewGRFMappingChunkHandler::NewGRFMappingChunkHandler().

Member Function Documentation

FixPointers()

virtual void ChunkHandler::FixPointers ( ) const

inlinevirtual

Fix the pointers.

Pointers are saved using the index of the pointed object. On load, pointers are filled with indices and need to be fixed to point to the real object. Must be overridden if the chunk saves any pointer.

Reimplemented in BKORChunkHandler, CAPYChunkHandler, CHKPChunkHandler, CITYChunkHandler, DEPTChunkHandler, ERNWChunkHandler, INDYChunkHandler, LGRSChunkHandler, OBJSChunkHandler, ORDLChunkHandler, PLYRChunkHandler, ROADChunkHandler, STNNChunkHandler, STNSChunkHandler, and VEHSChunkHandler.

Definition at line 488 of file saveload.h.

GetName()

std::string ChunkHandler::GetName ( ) const

inline

Get the name of this chunk.

Returns

The chunks 4 letter name/unique identifier.

Definition at line 501 of file saveload.h.

Referenced by SlLoadCheckChunk(), SlLoadChunk(), and SlSaveChunk().

Load()

virtual void ChunkHandler::Load ( ) const

pure virtual

Load the chunk.

Must be overridden.

Implemented in AIPLChunkHandler, ANITChunkHandler, BKORChunkHandler, CAPAChunkHandler, CAPRChunkHandler, CAPYChunkHandler, CHKPChunkHandler, CHTSChunkHandler, CITYChunkHandler, CMDLChunkHandler, CMPUChunkHandler, DATEChunkHandler, DEPTChunkHandler, ECMYChunkHandler, EIDSChunkHandler, ENGNChunkHandler, ENGSChunkHandler, ERNWChunkHandler, GLOGChunkHandler, GOALChunkHandler, GRPSChunkHandler, GSDTChunkHandler, GSTRChunkHandler, IBLDChunkHandler, INDYChunkHandler, ITBLChunkHandler, LEAEChunkHandler, LEATChunkHandler, LGRJChunkHandler, LGRPChunkHandler, LGRSChunkHandler, M3HIChunkHandler, M3LOChunkHandler, MAP2ChunkHandler, MAP5ChunkHandler, MAP7ChunkHandler, MAP8ChunkHandler, MAPEChunkHandler, MAPHChunkHandler, MAPOChunkHandler, MAPSChunkHandler, MAPTChunkHandler, NAMEChunkHandler, NewGRFMappingChunkHandler, NGRFChunkHandler, OBJSChunkHandler, OPTSChunkHandler, ORDLChunkHandler, ORDRChunkHandler, PATSChunkHandler, PLYRChunkHandler, PRICChunkHandler, PSACChunkHandler, RAILChunkHandler, ROADChunkHandler, ROTTChunkHandler, SIGNChunkHandler, SRNDChunkHandler, STNNChunkHandler, STNSChunkHandler, STPAChunkHandler, STPEChunkHandler, SUBSChunkHandler, VEHSChunkHandler, VIEWChunkHandler, and WaterRegionChunkHandler.

Referenced by SlLoadChunk().

LoadCheck()

void ChunkHandler::LoadCheck ( size_t len = 0 ) const

virtual

Load the chunk for game preview.

Default implementation just skips the data.

Parameters

len	Number of bytes to skip.

Reimplemented in DATEChunkHandler, GLOGChunkHandler, MAPSChunkHandler, NGRFChunkHandler, PATSChunkHandler, and PLYRChunkHandler.

Definition at line 2182 of file saveload.cpp.

References _sl, Array, Riff, SlSkipArray(), SlSkipBytes(), SlTableHeader(), SparseArray, SparseTable, and Table.

Referenced by SlLoadCheckChunk().

Save()

virtual void ChunkHandler::Save ( ) const

inlinevirtual

Save the chunk.

Must be overridden, unless Chunk type is ChunkType::ReadOnly.

Reimplemented in AIPLChunkHandler, ANITChunkHandler, BKORChunkHandler, CAPAChunkHandler, CAPYChunkHandler, CHTSChunkHandler, CITYChunkHandler, CMDLChunkHandler, CMPUChunkHandler, DATEChunkHandler, DEPTChunkHandler, ECMYChunkHandler, EIDSChunkHandler, ENGNChunkHandler, ERNWChunkHandler, GLOGChunkHandler, GOALChunkHandler, GRPSChunkHandler, GSDTChunkHandler, GSTRChunkHandler, IBLDChunkHandler, INDYChunkHandler, ITBLChunkHandler, LEAEChunkHandler, LEATChunkHandler, LGRJChunkHandler, LGRPChunkHandler, LGRSChunkHandler, M3HIChunkHandler, M3LOChunkHandler, MAP2ChunkHandler, MAP5ChunkHandler, MAP7ChunkHandler, MAP8ChunkHandler, MAPEChunkHandler, MAPHChunkHandler, MAPOChunkHandler, MAPSChunkHandler, MAPTChunkHandler, NewGRFMappingChunkHandler, NGRFChunkHandler, OBJSChunkHandler, ORDLChunkHandler, PATSChunkHandler, PLYRChunkHandler, PSACChunkHandler, RAILChunkHandler, ROADChunkHandler, ROTTChunkHandler, SIGNChunkHandler, SRNDChunkHandler, STNNChunkHandler, STPAChunkHandler, STPEChunkHandler, SUBSChunkHandler, VEHSChunkHandler, and VIEWChunkHandler.

Definition at line 474 of file saveload.h.

Referenced by SlSaveChunk().

Field Documentation

id

ChunkId ChunkHandler::id

Unique ID (4 letters).

Definition at line 457 of file saveload.h.

Referenced by ChunkHandler(), NewGRFMappingChunkHandler::NewGRFMappingChunkHandler(), and SlSaveChunk().

type

ChunkType ChunkHandler::type

Type of the chunk.

See also

ChunkType

Definition at line 458 of file saveload.h.

Referenced by ChunkHandler(), and SlSaveChunk().

---

The documentation for this struct was generated from the following files:

• src/saveload/saveload.h
• src/saveload/saveload.cpp
